WG600F Intelligent Industrial Peristaltic Pump

€3.279,00
Unit price per
(excl. VAT)

Shipping calculated at checkout.

The WG600F pump is designed for efficient transfer and dispensing of large fluid volumes in industrial applications. Offering a flow range from 0.01 to 13 L/min per channel, its brushless servo motor drive with substantial torque ensures high rotating accuracy while remaining maintenance-free. Beyond essential functions like reversible direction, start/stop, full speed (for rapid cleaning), and variable speed, it introduces three distributing modes: time dispensing mode, volume dispensing mode, and loop dispensing mode, catering to diverse and complex dispensing needs. Enhanced control is facilitated through the RS485 MODBUS interface, allowing seamless external control via devices such as computers, human-machine interfaces, or PLCs.

Functions and Features

Color LCD, touch screen, and keypad for operating.
Easy keypad control to reverse direction, start/stop, and run full speed (for cleaning).
Brushless servo motor drive with large torque, maintenance-free, high rotating accuracy.
Flow rate calibration.
Three types of distributing mode: time dispensing mode; volume dispensing mode; copy dispensing mode.
Automatically store five groups of working parameters.
Anti-interference feature, wide input voltage range for complex power environment.
The circuit board with conformal coating makes it dust-proof and moisture-proof.
External on/off voltage signal controls the start/stop, reversible direction, and easy dispensing function, optically coupled isolator. The external analogue control signal adjusts the rotating speed.
RS485 MODBUS interface allowing easy communication with other devices.
Stainless steel housing, easy to clean, excellent resistance to corrosion of acids, alkalis, sodium, and organic solvents.
Remote infrared control (optional).

Specifications

Flow range: 0.01-13 L/min
Speed range: 0.1-600 rpm
Speed resolution: 0.1 rpm
Speed accuracy: ±0.2%
Power supply: AC100-240V, 50Hz/60Hz
Power consumption: <300W
External on/off control: 5V, 12V (standard), 24V (optional); External analog control: 0-5V (standard); 0-10V, 4-20mA (optional)
Communication interface: RS485 MODBUS interface
Operating condition: Temperature 0-40°C; Relative humidity <80%
IP grade: IP31
Dimensions (L x W x H): 667×466×537 mm
Weight: 15 kg

WG600F Compatible Pump Heads and Tubing, Flow Parameters

Drive type	Pump head	Channel	Tubing size (mm)	Flow rate per channel (L/min)
WG600F	YZ35	1	73# 82#	0.01-13
WG600F	2 x YZ35	2	73# 82#	0.01-13

Dimensions (mm)

Click here to download the operating manual.
