CT3000F Micro Dispensing Gear Pump
The CT3000F intelligent dispensing gear pump offers efficient transfer of high-pressure and viscous liquids with pulsation-free operation and low noise, offering a precise flow range of 15-2700 mL/min depending on the pump head and speed settings. Its brushless servo motor drive ensures high precision and minimal maintenance. A colour LCD display and touch-screen interface allow easy flow adjustment. The built-in RS485 MODBUS communication interface allows seamless connection with external systems such as PCs, HMIs, or PLCs for monitoring and remote control.
Functions and Features
- Color LCD display with touchcreen operation
- Supports multiple operating modes including Flow Mode, Time Dispense, Volume Dispense, Copy Dispense
- External signal control for start/stop, direction, and speed
- Compatible with various pump heads
- Magnetic coupling for easy maintenance
- Pulsation-free transfer and low noise levels
- Brushless servo drive, high efficiency, high accuracy, maintenance-free
- Efficient transfer of high-pressure, viscous liquids
Specifications
- Pump Head: MS204, MS209, MS213 (PEEK gear material)
- Flow Range: 15-2700 mL/min
- Speed Range: 50-3000 rpm
- Speed Resolution: 1 rpm
- Direction: One direction
- Liquid Viscosity: ≤ 200 cSt
- Particle Size: ≤ 10 μm
- Control Mode: Flow Mode, Time Dispense, Volume Dispense, Copy Dispense
- Power Supply: AC 100-240V, 50Hz/60Hz
- Power Consumption: <150W
- External Control: 5V (12V/24V optional) for Start/Stop, 0-5V (0-10V, 4-20mA optional) for speed
- Power-Off Memory: Retains parameters set before power loss
- Communication interface: RS485 MODBUS
- Display: Colour LCD
- Operating Conditions: Temperature 0–40°C; Relative humidity <80%
- Dimensions (L × W × H): 320 × 150 × 237 mm
- Drive Weight: 5.5 kg
- IP Standard: IP31
CT3000F Compatible Pump Heads
| Pump Head | Gear Material | Max Output Pressure | Flow Range | Liquid Temperature |
|---|---|---|---|---|
| MS204 | PEEK | 1.4 MPa (203 psi) | 15-900 mL/min | -45-120°C |
| MS209 | PEEK | 0.9 MPa (131 psi) | 30-1800 mL/min | -45-120°C |
| MS213 | PEEK | 0.8 MPa (116 psi) | 45-2700 mL/min | -45-120°C |
